Sunix SER6437A PCIE 2-port RS-232 Low Profile PCI Express Board Expands two independent RS-232 serial ports with communication speeds up to 115.2Kbps. With high reliable SUNIX SUN2212 native PCI Express 16C950 UART controller. Designed to meet PCI Express Base Specification Revision 2.0. Supports x1, x2, x4, x8, x16 (lane) PCI Express Bus connector keys. On-chip hardware auto flow control to guarantee no data loss. Built-in ± 15KV ESD protection for all serial signals meets IEC1000-4-2 standard. Plug-n-Play, I/O address and IRQ assigned by BIOS. Low profile bracket design idea for slim or portable PC. Certified by CE, FCC, RoHS, and Microsoft WHQL approval. Support Microsoft Windows, Linux, and DOS. General Interface RS-232 Controller SUNIX SUN2212 (16C950 UART Compatible) BUS PCI Express Spec 2.0, Single-Lane (x1) IRQ & IO Assigned by System Serial Communication Interface RS-232 No. of Port 2-port FIFO 128byte Hardware Signal DCD, TxD, RxD, RTS, CTS, DTR, DSR, GND, RI Baud rate 50bps ~ 115.2Kbps Stop bit 1, 1.5, 2 Parity even, odd, none, mark, space Flow Control None, Xon/Xoff, RTS/CTS Protection ±15KV ESD protection for each signal Human Body Model (HBM) ±15KV IEC1000-4-2 Air Gap Discharge ±8KV IEC1000-4-2 Contact Discharge PCB Connector DB44 Female Driver Support Windows Client XP / Vista / 7 / 8.x / 10 (X86/X64) Windows Server 2003 / 2008 / 2012 / 2016 (X64) Windows Embedded XP Embedded / POSReady 2009 / POSReady / Embedded System 2009 Linux Linux 2.x / 3.x / 4.x / 5.3 DOS DOS *UNIX FreeBSD / QNX / SCO OpenServer / SCO UnixWare / Solaris *IBM OS/2 WARP 3/WARP 4 Dimension PCB Dimension 65 x 88 mm Bracket Low Profile 80 mm Bracket Space 1

(SER6437AL)

12
SKU SER6437AL
Barcode # 4.71075E+12
Brand Sunix
Assembled Length 204.000m
Assembled Height 42.000m
Assembled Width 0.300m
